Bagan Konversi Ukuran Kawat

Meteran	SWG		B&S / AWG			Meteran	SWG		B&S / AWG
Meteran	inch	mm	inch	mm		Meteran	inch	mm	inch	mm
7/0	.500	12.70	–	–		23	.024	0.610	.0226	.0574
6/0	.464	11.79	.580	14.73		24	.022	0.559	.020	0.508
5/0	.432	10.97	.5165	13.12		25	.020	0.508	.018	0.457
4/0	.400	10.16	.460	11.68		26	.018	0.457	.01595	0.405
3/0	.372	9.45	.4095	10.40		27	.0164	0.417	.0142	0.361
2/0	.348	8.84	.365	9.27		28	.0148	0.376	.01265	0.321
0	.324	8.23	.325	8.26		29	.0136	0.345	.0113	0.287
1	.300	7.62	.2895	7.35		30	.0124	0.312	.010	0.254
2	.276	7.01	.2575	6.54		31	.0116	0.295	.00895	0.227
3	.252	6.40	.2295	5.83		32	.0108	0.274	.00795	0.202
4	.232	5.89	.204	5.18		33	.010	0.254	.0071	0.180
5	.212	5.39	.182	4.62		34	.0092	0.234	.0063	0.160
6	.192	4.88	.162	4.11		35	.0084	0.213	.0056	0.142
7	.176	4.47	.144	3.66		36	.0076	0.193	.005	0.127
8	.160	4.06	.1285	3.26		37	.0068	0.173	.00445	0.113
9	.144	3.66	.114	2.90		38	.006	0.152	.00395	0.100
10	.128	3.25	.102	2.59		39	.0052	0.132	.00353	0.090
11	.116	2.95	.091	2.31		40	.0048	0.122	.00315	0.080
12	.104	2.64	.0808	2.05		41	.0044	0.112	.0028	0.071
13	.092	2.34	.072	1.83		42	.004	0.102	.0025	0.064
14	.080	2.03	.0642	1.63		43	.0036	0.091	.0022	0.056
15	.072	1.83	.0571	1.45		44	.0032	0.081	.002	0.051
16	.064	1.63	.0508	1.29		45	.0028	0.071	.0018	0.046
17	.056	1.42	.0453	1.15		46	.0024	0.061	.0016	0.041
18	.048	1.22	.0403	1.02		47	.002	0.051	.0014	0.036
19	.040	1.02	.036	0.914		48	.0016	0.041	.0012	0.030
20	.036	0.914	.032	0.813		49	.0012	0.031	.0011	0.028
21	.032	0.813	.0285	0.724		50	.001	0.025	–	–
22	.028	0.711	.0253	0.643
